- Model: HX-3S-FL25A-A
- Size: about 56mm*45mm*1.2mm
- Over voltage range: 4.25~4.35V ± 0.05V
- Over discharge voltage range: 2.3~3.0V ± 0.05V
- Maximum operating current: 0~25A
- Maximum transient current: 34~40A
- Quiescent current: less than 30uA
- Internal resistance: less than 100Mohm
- Working temperature: -40℃ ~ +50℃
- Storage condition: -40℃ ~ +80℃
- Effective life: more than30000h
- Short circuit protection: Yes, delayed self recovery
- Supplier: FAMOUS ELECTRONICS BD
Upgrade 3S 25A BMS 11.1V 12.6V 18650 Lithium Battery Protection Circuit Board With Balanced
145 BDT310 BDTSave 165 BDT
Total sold : 32
- Model: HX-3S-FL25A-A
- Size: about 56mm*45mm*1.2mm
- Over voltage range: 4.25~4.35V ± 0.05V
- Over discharge voltage range: 2.3~3.0V ± 0.05V
- Maximum operating current: 0~25A
- Maximum transient current: 34~40A
- Quiescent current: less than 30uA
- Internal resistance: less than 100Mohm
- Working temperature: -40℃ ~ +50℃
- Storage condition: -40℃ ~ +80℃
- Effective life: more than30000h
- Short circuit protection: Yes, delayed self recovery
- Supplier: FAMOUS ELECTRONICS BD
